Narvi Confirmation Web Element

Overview

This document provides instructions for embedding the Narvi Confirmation Web Element using a <iframe> in your web application. The Narvi Confirmation Web Element allows for seamless integration of a confirmation process into your BaaS application with customizable appearance settings.

Embedding the Narvi Confirmation Web Element

To embed the element, you need to generate a source URL for the <iframe> using the provided parameters. Below are the steps to follow:

Encode the Payload: The payload containing the confirmation parameters needs to be encoded and converted to a Base64 string.
Generate the Source URL: Use the encoded payload to generate the source URL for the <iframe>.
Embed the <iframe>: Embed the <iframe> in your codebase, passing the generated URL as the src attribute.

Step-by-Step Instructions

Step 1: Generate Challenge Signature

Challenge signature should be generated in the following way:

concatenate challenge_pid, target (email or phone numer) and private public id
signature is the encoded base64 signature of challenge descriptor

123456789

{  "pid": "T83H6LH48MMYS497",  "kind": "EMAIL",  "number": 5,  "added": "1720954148.018724",  "target": "e******@example.com",  "expired": "1720954448.018724",  "resent": "1720954148.018748"}

T83H6LH48MMYS497example@example.com68156984

Step 2: Include <iframe> tag in your HTML Structure

1234567891011121314151617

<!DOCTYPE html><html lang="en">  <head>    <meta charset="UTF-8" />    <meta name="viewport" content="width=device-width, initial-scale=1.0" />    <title>BaaS Page</title>  </head>
  <body>    <iframe      id="challenge-frame"      style="height: 100%; width: 100%; border: none;"    ></iframe>
    <!-- Script will be added here in the following steps -->  </body></html>

Step 3: Add Event Listener for Messages

1234567

<script>  window.addEventListener('message', function (event) {    if (event.data.source === 'IFRAME_SOURCE') {      console.warn('Message received from iframe:', event.data)    }  })</script>

Each received message is an object with predefined fields

12345678910111213141516

enum ChallengeElementMessage {  Mounted = 'mounted',  Init = 'init',  Loading = 'loading',  Success = 'success',  Failure = 'failure',  Error = 'error',  Rejected = 'rejected',}
type MessagePayload = {  type: ChallengeElementMessage  text: string  additionalPayload?: object  source?: string}

List of possible challenge messages

ChallengeElementMessage.Mounted

Challenge UI element has been mounted

ChallengeElementMessage.Init

Challenge in pending state

ChallengeElementMessage.Loading

Challenge in loading state

ChallengeElementMessage.Success

Challenge succeeded

ChallengeElementMessage.Failure

Challenge failed

ChallengeElementMessage.Error

Error occurred during challenge

ChallengeElementMessage.Rejected

Challenge has been rejected

Step 4: Define the Function to Generate the Iframe Source URL

Use encode function from MessagePacker to encode the payload, then transform the encoded payload to a base64 string value.

123456

function getChallengeWebElementSource(payload) {        var encodedPayload = msgpack.encode(payload);        var base64Payload = Buffer.from(encodedPayload).toString('base64');
        return `https://api.narvi.com/challenge?payload=` + base64Payload;      }

Step 5: Set the Iframe Source URL

12345678910111213141516

var params = {  signature: 'YOUR_SIGNATURE',  apiKeyId: 'YOUR_API_KEY_ID',  challengeId: 'BAAS_CHALLENGE_ID',  appearance: {    textColor: 'white',    inputTextColor: 'blue',    inputBorderColor: 'black',    inputBackgroundColor: 'white',    resendButtonColor: 'green',    fontFamily: 'Arial, Helvetica, sans-serif',  },}
var iframeSrc = getChallengeWebElementSource(params)document.getElementById('challenge-frame').src = iframeSrc

Example code

123456789101112131415161718192021222324252627282930313233343536373839404142434445464748

<!DOCTYPE html><html lang="en">  <head>    <meta charset="UTF-8">    <meta name="viewport" content="width=device-width, initial-scale=1.0">    <title>BaaS Page</title>  </head>
  <body>    <iframe      id="challenge-frame"      style="height: 100%; width: 100%; border: none;"    ></iframe>
    <script>      function getChallengeWebElementSource(payload) {        var encodedPayload = msgpack.encode(payload);        var base64Payload = Buffer.from(encodedPayload).toString('base64');
        return `https://api.narvi.com/challenge?payload=` + base64Payload;      }
      var challengePayload = {        signature: 'YOUR_SIGNATURE',        apiKeyId: 'YOUR_API_KEY_ID',        challengeId: 'BAAS_CHALLENGE_ID',        appearance: {          textColor: 'white',          inputTextColor: 'blue',          inputBorderColor: 'black',          inputBackgroundColor: 'white',          resendButtonColor: 'green',          fontFamily: 'Arial, Helvetica, sans-serif'        }      };
      var iframeSrc = getChallengeWebElementSource(challengePayload);      document.getElementById('challenge-frame').src = iframeSrc;
      window.addEventListener('message', function(event) {        if (event.data.source === 'IFRAME_SOURCE') {          console.warn('Message received from iframe:', event.data);        }      });    </script>
  </body></html>

Explanation of Parameters

signature

A string representing the signature for the challenge process.

challengeId

A unique identifier for the challenge process.

apiKeyId

Api key id gathered from configured api key Developer Section

appearance

Optional

An object to customize the UI appearance of the challenge page.

appearance.inputTextColor

Color of the text inside input fields.

appearance.inputBorderColor

Border color of the input fields.

appearance.inputBackgroundColor

Background color of the input fields.

appearance.resendButtonColor

Color of the resend button.

appearance.fontFamily

Custom font family for the text.

Element playground

Challenge parameters

challengeId

signature

apiKeyId

Appearance fields

textColor

inputTextColor

inputBorderColor

inputBackgroundColor

resendButtonColor

fontFamily

Provide challenge parameters to see the preview.

Transformed payload in base64

"3gAEqXNpZ25hdHVyZcCrY2hhbGxlbmdlSWTAqGFwaUtleUlkwKphcHBlYXJhbmNl3gAGqXRleHRDb2xvcqcjNDI1Mzc2rmlucHV0VGV4dENvbG9ypyMxRjIwM0SwaW5wdXRCb3JkZXJDb2xvcqcjQ0VENUUztGlucHV0QmFja2dyb3VuZENvbG9ypyNGRkZGRkaxcmVzZW5kQnV0dG9uQ29sb3KnIzU3NTlBOKpmb250RmFtaWx5pkxleGVuZA=="
